• Qualified for Automotive Applications
• Available in an ESOP-8 Package

• Qualified for Automotive Applications
Device Temperature Grade 1: –40°C to
125°C Ambient Operating Temperature Range
Device HBM ESD Classification Level H1C
Device CDM ESD Classification Level C3B
• High-Efficiency at Light Loads With Pulse-Skipping
Eco-mode™
• 92-mΩ High-Side MOSFET
• 146-μA Operating Quiescent Current and 2-µA
Shutdown Current
• 100-kHz to 2.5-MHz Adjustable Switching Frequency
• Synchronizes to External Clock
• Low Dropout at Light Loads With Integrated BOOT
Recharge FET
• Adjustable UVLO Voltage and Hysteresis
• 0.8-V 1% Internal Voltage Reference
• 8-Pin HSOP PowerPAD™ Package
• –40°C to 150°C TJ Operating Range
• Supported by WEBENCH® Software Tool
