• Wide Input Range: 5.5V-100V

• Maximum Output Voltage: 30V

• 2A Continuous Output Current

• 4A Peak Current Limit

• Integrated 500mΩ High-Side Power MOSFETs

• 140uA Quiescent Current

• 1.2V ±2% Feedback Reference Voltage

• 4ms Internal Soft-start Time

• Fixed Switching Frequency at 300KHz

• COT Control Mode with Integrated Loop Compensation

• Precision Enable Threshold for Programmable Input

  Voltage Under-voltage Lock Out Protection (UVLO)

  Threshold and Hysteresis

• Cycle-by-Cycle Current Limiting

• Over-Voltage Protection

• Over-Temperature Protection
