• Covers full GNSS L1 band, from 1559 MHz to 1610 MHz

• Noise figure (NF) = 0.85 dB

• Gain 16.5 dB

• High input 1 dB compression point Pi(1dB) of -11 dBm

• High out of band IP3_i of 9 dBm

• Supply voltage 1.5 V to 3.1 V

• Power-down mode current consumption < 1 mA

• Optimized performance at low supply current of 4.5 mA

• Integrated matching for the output

• Requires only one input matching inductor and one supply

  decoupling capacitor

• Input and output DC decoupled

• ESD protection on all pins (HBM > 2 kV)

• Integrated temperature stabilized bias for easy design

• Small 6-pin leadless package 1 mm ´ 1.45 mm ´ 0.5 mm

• 110 GHz transit frequency - SiGe:C technology
