• Integrated high performance 2.4 GHz PA, harmonic

  filter, LNA with bypass, and T/R switch

• Fully-matched input and output

• LNA with integrated bypass mode

• High performance SP3T switch to support Bluetooth

  /WiFi functions

• Transmit loopback mode

• Integrated positive slope power detector

• Transmit gain: 26 dB

• Receive gain: 14 dB

• Output power:

  − +18 dBm @ 1.8% EVM, MCS8, HT20

  − +19 dBm @ 3% EVM, MCS7, HT20

• Direct connection to battery with 3.6 V nominal supply

• Small, QFN (16-pin, 2.5 x 2.5 x 0.4 mm) package

 (MSL1, 260 °C per JEDEC J-STD-020)
