• Integrated high-performance 2.4 GHz PA, harmonic

  filter,  LNA with bypass, and T/R switch

• Fully-matched input and output

• LNA with integrated bypass mode

• High performance SP3T switch to support Bluetooth

  /WiFi functions

• Integrated positive slope power detector

• Transmit gain: 30 dB

• Receive gain: 12 dB

• Small QFN (16-pin, 3 x 3 mm) package

  (MSL1, 260 °C per JEDEC J-STD-020)
