• Rail-to-Rail Output 2mV Typical VOS

• High Speed

  350MHz, -3dB Bandwidth (G = +1)

  265V/μs, Slew Rate

  32ns Settling Time to 0.1% with 2V Step

• Operates on 2.5V to 5.5V Supplies

• Input Voltage Range = -0.2V to +3.8V with VS = 5V

• Excellent Video Specs (RL = 150Ω, G = +2)

  Gain Flatness 0.1dB to 70MHz

  Diff Gain: 0.004%, Diff Phase: 0.08 degree

• Low Power 4.3mA/Amplifier Typical Supply Current

• Small Packaging

  SGM8092 Available in SOIC-8 and MSOP-8
