SGM836.pdf• Adjustable Reset Timeout Period: 1.25ms to 10s
• Low Quiescent Current: 0.6μA (TYP)
• High Threshold Accuracy: 1% (TYP)
• Factory-Set Detection Voltages from 0.9V
to 5V and Adjustable Detection Voltage Down to 0.4V
• Manual Reset (nMR) Input
• Open-Drain nRESET Output
• -40℃ to +125℃ Operating Temperature Range
• Available in Green SOT-23-6 and TDFN-2×2-6AL Packages
• Fixed Threshold Voltages for Standard
Voltage Rails From 0.9V to 5V and
Adjustable Voltage From 0.4V are Available
• Low Quiescent Current: 1.6uA typ
• Power-On Reset Generator with Adjustable
Delay Time: 2.1ms to 10s
• High Threshold Accuracy: ±1% typ
• Manual Reset (MR) Input
• Open-Drain RESET Output
• Immune to Short Negative SENSE voltage
• Guaranteed Reset Valid to VCC=0.8V
• 6 Pin TSOT23 and 2mm×2mm QFN
• DSP or Micro controller Applications
• Laptop/Desktop Computers
• PDAs/Hand-Held Products
• Portable/Battery-Powered Products
• FPGA/ASIC Applications
