• Wide Supply Ranges Dual Supplies: ±1.5V to ±16V

• Low Quiescent Current: 860μA (TYP)

• Gain-Bandwidth Product: 1.1MHz

• Input Common Mode Voltage Range Includes Ground,

  Allowing Direct Sensing Near Ground

• Low Input Offset Voltage: 5.8mV (MAX)

• Low Input Offset Current: 20pA (TYP)

• Low Input Bias Current: 10pA (TYP)

• Differential Input Voltage Range Equal to Maximum- Rated Supply Voltage: 32V

• Open-Loop Differential Voltage Gain: 111dB (TYP)

• Internal Frequency Compensation

• -40℃ to +125℃ Operating Temperature Range

• Available in a Green SOIC-14 Package

The LM2902 consists of four independent, high-gain frequency-compensated operational amplifiers designed to operate from a single supply or dual supplies over a wide range of voltages.

The LM2902 is available in a Green SOIC-14 package. It is specified over the -40℃ to +125℃ temperature range.
