3.8V-28V Vin, 3A Asynchronous Step-down DCDC Converter, SCT9331C Replace TPS5402.
FEATURES

• EMI Reduction with Switching Node Ringing-free

• 400kHz Switching Frequency with 6% Frequency
  Spread Spectrum (FSS)
• Pulse Skipping Mode PSM with 25uA Quiescent
  Current in Light Load Condition
• 3.8V-28V Wide Input Voltage Range
• Up to 3A Continuous Output Load Current
• 0.8V ±1% Feedback Reference Voltage
• Fully Integrated 115mΩ Rdson High Side MOSFET
• 1uA Shutdown Current
• 80ns Minimum On-time
• Precision Enable Threshold for Programmable
  UVLO Threshold and Hysteresis
• 4ms Built-in Soft Start Time
• Output Over Voltage Protection
• Thermal Shutdown Protection at 160°C
• Available in SOP-8L Package
PIN CONFIGUTION
CROSS
TPS5402 TPS5402.pdf

No.14448

FEATURES

• 3.5-V to 28-V Wide Input Voltage Range

• Up to 1.7-A Maximum Continuous Output

  Loading Current

• Pulse Skipping Mode to Achieve High Light

  Load Efficiency

• High Light Load Efficiency

• Frequency Spread Spectrum to Reduce EMI

• Adjustable 50-kHz to 1.1-MHz Switching

  Frequency Set by an External Resistor

  (Leave pin ROSC floating. Set frequency to

  120 kHz and ground connection to 70 kHz)

• Frequency Spread Spectrum to Ease EMI Issue

• Peak Current-Mode Control

• Cycle-by-Cycle Over Current Protection

• External Soft Start

• Available in SOIC8 Package


PIN CONFIGUTION
